可選測頭

Applicable measuring probes:

軸向測頭Axial probes P-A2, P-W2 and P-A4,
切向測頭Tangential probes P-T2, P-T4, P-Z2, P-Z4 and P-T4A.

直流測量范圍

Measuring range DC:

0-40,000 A/cm

交流測量范圍

Measuring range AC:

20-20,000 A/cm

精度

Accuracy:

in the homogeneous field
0-20,000 A/cm ± 2% ± 1 digit,
> 20,000 A/cm ± 3% of the displayed value ± 1 digit

分辨率

Resolution:

0 - 200 A/cm: 0.1 A/cm,
> 200 A/cm: 1 A/cm,
> 10,000 A/cm: 10 A/cm

頻率范圍

Frequency range AC:

10 Hz – 5 KHz

峰值保持

Peak Hold:

Impulse duration >= 0.1 msec

顯示

Display:

graphical PLC operating terminal with menu guidance, display of measured values digital or analog, and trend measurement帶菜單引導、數字或模擬測量值顯示和趨勢測量的圖形PLC操作終端

多語言

Multilingual menu navigation:

German / English

數據記錄

Data logger:

500次測量

統計Statistics:

計數/大/小/平均/標準偏差

Count / Maximum / Minimum / Average / Standard deviation

連接

Interface:

RS232接口，帶USB線與PC機通訊，過程控制用24伏模擬信號接口

RS232 interface with USB cable for communication with PC, 24V analog signal interface for process control

供電Power supply:

230V

尺寸Dimensions:

145 x 145 x 220 mm

重量Weight:

1.8KG
